Side by side

XQD versus CFexpress Type B

A shared form factor does not establish device or firmware support.

Computer-generated illustration, not a photograph. — P123 · ConnectorXQD card interface

How they differ

XQD card interface Read the XQD marking and the exact reader and camera descriptions. Keep model-specific firmware notes attached to that model.
CFexpress Type B card interface Read Type B on the card and the exact supported-media list; record the camera firmware requirement where one is given.

At a glance

Source-scoped form facts; counts, variants and unknowns are distinct
Field	XQD card interface	CFexpress Type B card interface
Type	Connector	Connector
Family	Storage	Storage
Shape	card edge	card edge
Nominal contacts	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Positions / cavity span	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Contact rows	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Connector role	XQD removable memory card (SonyQD-G120F G-series XQD card in current product table)S949Current primary-source scoped values; named examples remain separate and unknowns are not inferred from illustrations. SonyQD-G120F G-series XQD card in current product table	card (CEB-G128)S098Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. CEB-G128. Documented role: card. Approximate dimensions of named CEB-G models. No XQD electrical compatibility inferred merely from shared physical form.
Key distinction	A shared form factor does not approve a replacement card.	Same shell is not the same supported media.

Full evidence ledger and sources ↓

Illustrations are computer-generated with prior AI visual review; independent technical and rights review pending. A comparison is not a compatibility verdict.

This comparison stays within one evidence layer.

All selected records are Connector records. Similar layer does not mean compatible, interchangeable or safe to mate.

Families represented: Storage

Application comparison / concept only

A shared form, a separate support list

CFexpress Type B and XQD need device evidence.

CFexpress Type B →XQD →

Not a general compatibility verdict. S096 · S495

The reference ledger

Read the same question across.

2 selected records · 15 fields
No score. No compatibility verdict.

On a narrow screen, scroll the table sideways or open the field-by-field reading view below. Illustrations are not a size comparison.

Comparison of selected field notes; source links accompany each documented specification
What you are comparing	P123 / ConnectorXQD card interface Identification schematic · not to scale · drawing review pending	P122 / ConnectorCFexpress Type B card interface Identification schematic · not to scale · drawing review pending
Layer	Connector	Connector
Key distinction	A shared form factor does not approve a replacement card.	Same shell is not the same supported media.
Nominal contacts	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Positions / cavity span	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Populated contacts	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Contact rows	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Contact pitch	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Dimensions / axis	29.6 mm whole-card width W (SonyQD-G120F G-series XQD card in current product table); 38.5 mm whole-card length L (SonyQD-G120F G-series XQD card in current product table); 3.8 mm whole-card thickness T (SonyQD-G120F G-series XQD card in current product table)S949Current primary-source scoped values; named examples remain separate and unknowns are not inferred from illustrations. SonyQD-G120F G-series XQD card in current product table; approximately	29.6 mm approximate overall width (CEB-G128); 38.5 mm approximate overall length (CEB-G128); 3.8 mm approximate overall thickness (CEB-G128)S098Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. CEB-G128. Documented role: card. Approximate dimensions of named CEB-G models. No XQD electrical compatibility inferred merely from shared physical form.
Connector role	XQD removable memory card (SonyQD-G120F G-series XQD card in current product table)S949Current primary-source scoped values; named examples remain separate and unknowns are not inferred from illustrations. SonyQD-G120F G-series XQD card in current product table	card (CEB-G128)S098Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. CEB-G128. Documented role: card. Approximate dimensions of named CEB-G models. No XQD electrical compatibility inferred merely from shared physical form.
Coupling / latch	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Keying / polarization	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.	Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Documented identification	Sony G-series examples are explicitly XQD cards using a PCI Express interface.C123A	The CompactFlash Association states that Type B and XQD share a form factor and connector, with camera support conditional on implementation.C122A
Important distinction	The CompactFlash Association describes the shared XQD / CFexpress Type B form factor without guaranteeing universal compatibility.C123B	Sony labels its CEB-G card examples CFexpress Type B with a PCI Express interface.C122B
Documented distinction	Not an equivalent field	CFA describes CFexpress Type B as using two PCIe lanes and retaining the same dimensions and connector as XQD. It separately makes camera support conditional on implementation or a manufacturer update.C122C
Evidence	C123A,C123B,C123C,C123D,C123E → Independent review pending	C122A,C122B,C122C,C122D → Independent review pending

Read field by field — no sideways scrolling

The same selected records, fields, values and source links as the table. Missing fields remain non-equivalent; no values are merged.

Layer

XQD card interfaceP123 / Connector: Connector
CFexpress Type B card interfaceP122 / Connector: Connector

Key distinction

XQD card interfaceP123 / Connector: A shared form factor does not approve a replacement card.
CFexpress Type B card interfaceP122 / Connector: Same shell is not the same supported media.

Nominal contacts

XQD card interfaceP123 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
CFexpress Type B card interfaceP122 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.

Positions / cavity span

XQD card interfaceP123 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
CFexpress Type B card interfaceP122 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.

Populated contacts

XQD card interfaceP123 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
CFexpress Type B card interfaceP122 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.

Contact rows

XQD card interfaceP123 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
CFexpress Type B card interfaceP122 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.

Contact pitch

XQD card interfaceP123 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
CFexpress Type B card interfaceP122 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.

Dimensions / axis

XQD card interfaceP123 / Connector: 29.6 mm whole-card width W (SonyQD-G120F G-series XQD card in current product table); 38.5 mm whole-card length L (SonyQD-G120F G-series XQD card in current product table); 3.8 mm whole-card thickness T (SonyQD-G120F G-series XQD card in current product table)S949Current primary-source scoped values; named examples remain separate and unknowns are not inferred from illustrations. SonyQD-G120F G-series XQD card in current product table; approximately
CFexpress Type B card interfaceP122 / Connector: 29.6 mm approximate overall width (CEB-G128); 38.5 mm approximate overall length (CEB-G128); 3.8 mm approximate overall thickness (CEB-G128)S098Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. CEB-G128. Documented role: card. Approximate dimensions of named CEB-G models. No XQD electrical compatibility inferred merely from shared physical form.

Connector role

XQD card interfaceP123 / Connector: XQD removable memory card (SonyQD-G120F G-series XQD card in current product table)S949Current primary-source scoped values; named examples remain separate and unknowns are not inferred from illustrations. SonyQD-G120F G-series XQD card in current product table
CFexpress Type B card interfaceP122 / Connector: card (CEB-G128)S098Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. CEB-G128. Documented role: card. Approximate dimensions of named CEB-G models. No XQD electrical compatibility inferred merely from shared physical form.

Coupling / latch

XQD card interfaceP123 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
CFexpress Type B card interfaceP122 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.

Keying / polarization

XQD card interfaceP123 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
CFexpress Type B card interfaceP122 / Connector: Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.

Documented identification

XQD card interfaceP123 / Connector: Sony G-series examples are explicitly XQD cards using a PCI Express interface.C123A
CFexpress Type B card interfaceP122 / Connector: The CompactFlash Association states that Type B and XQD share a form factor and connector, with camera support conditional on implementation.C122A

Important distinction

XQD card interfaceP123 / Connector: The CompactFlash Association describes the shared XQD / CFexpress Type B form factor without guaranteeing universal compatibility.C123B
CFexpress Type B card interfaceP122 / Connector: Sony labels its CEB-G card examples CFexpress Type B with a PCI Express interface.C122B

Documented distinction

XQD card interfaceP123 / Connector: Not an equivalent field
CFexpress Type B card interfaceP122 / Connector: CFA describes CFexpress Type B as using two PCIe lanes and retaining the same dimensions and connector as XQD. It separately makes camera support conditional on implementation or a manufacturer update.C122C

Evidence

XQD card interfaceP123 / Connector: C123A,C123B,C123C,C123D,C123E →
Independent review pending
CFexpress Type B card interfaceP122 / Connector: C122A,C122B,C122C,C122D →
Independent review pending

Your next step

Use the distinction in context.

Open the field notes Read source-linked facts and limitations.Compare another pair Start from a common confusion.Check a connection A comparison is not a compatibility verdict.

Continue the distinction

Compare next

Browse every comparison →

CFast versus CFexpress Type BSATA CFast is not PCIe/NVMe CFexpress. Check the full card and reader names before checking performance.CFexpress Type A versus Type BRecord the type letter and supported reader, not just the family name.CompactFlash versus CFexpress Type BPATA CompactFlash and PCIe/NVMe CFexpress are different card families; a CF reader label is incomplete.Mini-SAS HD vs OCuLinkMini-SAS HD and OCuLink are different connector families used in high-speed internal links. Physical resemblance is not evidence of mating or protocol compatibility.Mini-SAS HD vs SlimSASMini-SAS HD and SlimSAS are different internal high-density connector families. Match the named SFF form and system documentation, not the general SAS label.SATA data vs SATA powerSATA data and SATA power are separate connectors with different roles and contact counts. Sharing the SATA name does not make them substitutes.

Adjust this comparison

Add a field note

Evidence behind this page

Scope first. Source second. Approval separate.

5 linked sources · 9 scoped claims · 0 sources with inspection/access flags.

Page scope: Evidence behind the compared records; the editorial comparison still needs separate review.

Assessment 2026-10-22 · earliest scheduled source review 2027-01-01. This is a recorded-date assessment, not a live source check. Page-level independent review is not established by this panel.

Inspect 5 source scopes, access limits and dates

S096 · Card types and form-factor distinctions

CompactFlash Association · Standards-organization domain · inspected 2026-10-03 · due 2027-01-01

Within inspection window

Scoped support: CF uses PATA; CFast uses SATA; CFexpress uses PCIe/NVMe; Type B and XQD share a form factor but camera support is conditional.

Not established / limitations: No copied tables, logos, numeric throughput promises, exhaustive market status or licensed normative specification. Text-only scope.

Locator: CFexpress Form Factors; Type A versus Type B; Legacy Standards

S097 · XQD G-series product support — interface identity

Sony · Manufacturer / product-owner domain · inspected 2026-10-03 · due 2027-01-01

Within inspection window

Scoped support: Named XQD G-series examples have a PCI Express interface; the XQD family name must be recorded.

Not established / limitations: Japanese primary text inspected. Device-family rows are not a universal XQD speed, voltage or firmware guarantee.

Locator: G-series product information and interface rows

S098 · CFexpress Type B CEB-G support — interface identity

Sony · Manufacturer / product-owner domain · inspected 2026-10-03 · due 2027-01-01

Within inspection window

Scoped support: Sony CEB-G examples explicitly identify CFexpress Type B and PCI Express.

Not established / limitations: Japanese primary text inspected. Model-specific performance and dimensions are not transferred to every card.

Locator: CEB-G product information; interface row

S495 · MRW-G1 CFexpress Type B / XQD reader supported cards

Sony · Unclassified publisher domain · inspected 2026-10-11 · due 2027-01-09

Within inspection window

Scoped support: Named reader support only, not all XQD readers, all camera slots or all brands.

Not established / limitations: Named example only. No universal compatibility or publication approval. Raw-byte acquisition status is recorded separately.

Locator: Product description and FAQ: supported Sony CFexpress Type B and Sony XQD G/M series cards.

S949 · XQD memory card G-series product information and support

Sony · Manufacturer / product-owner domain · inspected 2026-10-22 · due 2027-01-20

Within inspection window

Scoped support: Named Sony G-series card example QD-G120F: approximate whole-card dimensions and listed interfaces, not contact geometry.

Not established / limitations: Japanese table explicitly labels W/L/T and approximate values. No card contact count,pitch,slot fit,CFexpress interchangeability,reader support or data rate inferred from shared size. Product photo not treated as a labelled exact card model view.

Locator: CurrentQD-G240F/QD-G120F/QD-G64F/QD-G32E table: interface,outerdimensions(WxLxT),capacity; separate discontinued model table.

Trace 9 claims to their source records

C122A · P122

The CompactFlash Association states that Type B and XQD share a form factor and connector, with camera support conditional on implementation.

Claim scope: Identification and explicitly scoped documentation only; not an end-to-end connection approval

Source links: S096 · Evidence trail → (private workspace)

C122B · P122

Sony labels its CEB-G card examples CFexpress Type B with a PCI Express interface.

Claim scope: Identification and explicitly scoped documentation only; not an end-to-end connection approval

Source links: S098 · Evidence trail → (private workspace)

C122C · P122

CFA describes CFexpress Type B as using two PCIe lanes and retaining the same dimensions and connector as XQD. It separately makes camera support conditional on implementation or a manufacturer update.

Claim scope: Card Types public text: form-factor footnote and A/B FAQ; no dimensions or speed table transcribed.

Source links: S096 · Evidence trail → (private workspace)

C122D · P122

Sony lists its CFexpress Type B memory cards for the MRW-G1 reader.

Claim scope: Sony MRW-G1 and the specified Sony card family only. No camera or other reader approval.

Source links: S495 · Evidence trail → (private workspace)

C123A · P123

Sony G-series examples are explicitly XQD cards using a PCI Express interface.

Claim scope: Identification and explicitly scoped documentation only; not an end-to-end connection approval

Source links: S097 · Evidence trail → (private workspace)

C123B · P123

The CompactFlash Association describes the shared XQD / CFexpress Type B form factor without guaranteeing universal compatibility.

Claim scope: Identification and explicitly scoped documentation only; not an end-to-end connection approval

Source links: S096 · Evidence trail → (private workspace)

C123C · P123

Sony lists XQD G-series and M-series memory cards for the MRW-G1 reader.

Claim scope: Sony MRW-G1 and these named Sony XQD series only; a shared slot outline does not transfer this support to another reader.

Source links: S495 · Evidence trail → (private workspace)

C123D · P123

Sony lists its named G-series XQD cards at approximately 29.6 mm width, 38.5 mm length and 3.8 mm thickness, with the table explicitly ordered W/L/T.

Claim scope: SonyQD-G120F G-series XQD card in current product table;approximate whole-card envelope only,not cardcontact/slot dimensions.

Source links: S949 · Evidence trail → (private workspace)

C123E · P123

Sony lists QD-G120F as a 120 GB G-series XQD card and names PCI Express 3.0 and USB 3.1 Gen 1 in the interface row.

Claim scope: SonyQD-G120F G-series XQD card in current product table only;no arbitraryreader support,negotiated rate or CFexpress interchangeability.

Source links: S949 · Evidence trail → (private workspace)

Prepare this page for review →Read the evidence method →

Recorded evidence only. An inspection date, publisher label, source link or generated packet is not independent technical review, hardware testing, fabrication approval or a compatibility verdict.
