OSFP uses a 60-position host interconnect form in the documented Amphenol family. [C221A]
Molex2139120022 is an OSFP female right-angle surface-mount connector with60loadedcircuits, manufacturer NumberOfRows1,0.60mm mating pitch, copper-alloy contacts with gold mating plating and a high-temperature thermoplastic housing. [C221W]
Source-scoped identification facts
Each value retains its exact example, role and measurement axis. Facts from different parts must not be combined into an invented component.
| Nominal contacts | 60S226Source-backed nominal position count: 60. |
|---|---|
| Positions / cavity span | 60 (Claim C221A); 60 (Claim C221B)S226 · S246Recorded source-scoped values; named examples do not describe every family variant or establish compatibility. V39 catalogue-expansion identification fact only; not independent technical approval, fabrication data, wiring instruction, protocol guarantee or end-to-end compatibility proof. V40 engineering-reference fact only; independent human review remains pending. This claim does not approve fabrication, rewiring, substitution, electrical safety, protocol support or end-to-end compatibility. |
| Contact rows | 1 (Molex2139120022)S992Qualified exact source facts only; counterpart, mounting-acceptance, cable, port, termination and assembly context remains separately labelled in variant_notes. Exact Molex2139120022 OSFP female right-angle SMT connector; not a cage port matrix, genericOSFP assignment or reconstructed face. Quantity context: Manufacturer Number Of Rows property. |
| Contact pitch | 0.6 mm Example connector centerline / pitch (Recorded example component); 0.6 mm Source-described pitch / centerline (Claim C221B); 0.6 mm centerline (2324869-1)S246 · S246Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. example_component; OSFP host connector example V40 engineering-reference fact only; independent human review remains pending. This claim does not approve fabrication, rewiring, substitution, electrical safety, protocol support or end-to-end compatibility. 2324869-1. Documented role: socket. Page establishes SMT host connector and60positions; no new row count, face dimension or keying shape inferred. Existing profile is retained. |
| Manufacturer | TE Connectivity (2324869-1)S246Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. 2324869-1. Documented role: socket. Page establishes SMT host connector and60positions; no new row count, face dimension or keying shape inferred. Existing profile is retained. |
| Series | OSFP (2324869-1)S246Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. 2324869-1. Documented role: socket. Page establishes SMT host connector and60positions; no new row count, face dimension or keying shape inferred. Existing profile is retained. |
| Exact part / implementation | 2324869-1 (2324869-1)S246Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. 2324869-1. Documented role: socket. Page establishes SMT host connector and60positions; no new row count, face dimension or keying shape inferred. Existing profile is retained. |
Not recorded: Populated contacts, Dimensions / axis, Connector role, Contact gender / arrangement, Mounting, Coupling / latch, Keying / polarization, Shell / form, Recorded markings, View convention. Unknown fields stay unknown; illustrations supply no measurements or pin assignments.
Recorded variant and source limits
- Position/contact count and any example-component pitch do not establish a universal pinout, cable construction or protocol capability.
- No fabrication dimensions or face-view pin locator is published unless explicitly stated.
- Prior view context (not a source-view value): Position count is published without a V40 mating-face numbering locator.
Bounded facts, visible unknowns
Specifications and limits
| Documented identification | OSFP 60-position host interconnect form. [C221A] |
|---|---|
| Mechanical dimensions | No independently reviewed mechanical drawing in V39; do not use this page for fabrication, fit testing or tolerance work. |
| Engineering pinout | Source-checked engineering profile available; independent review pending. Open engineering profile → |
| Verified device list | Not included. Check exact device and accessory documentation. |
Use the source-backed form or position count only for identification. Resolve ratings, protocol, direction, wiring, cable construction and exact device support from the relevant equipment and component documentation.
Before you connect
What to check
- Identify the exact connector family and variant from the equipment or cable documentation.
- Keep shape, contact count, protocol, electrical rating and device support as separate facts.
- Do not force, rewire or adapt a connector from this recognition record; resolve the remaining requirements first.
What is not established
This field note does not approve a connection, adapter, cable assembly, rewiring scheme or fabricated part. It intentionally omits unsupported pin assignments and mechanical tolerances.
