4-pin Mini-XLR (Switchcraft Tini-QG) connector Confirm the compact Mini-XLR/Tini-QG form and 4-conductor variant; do not substitute it for full-size XLR or infer a wiring scheme from pole count.
5-pin Mini-XLR (Switchcraft Tini-QG) connector Confirm the compact Mini-XLR/Tini-QG form and 5-conductor variant; do not substitute it for full-size XLR or infer a wiring scheme from pole count.
At a glance
Source-scoped form facts; counts, variants and unknowns are distinct
Field
4-pin Mini-XLR (Switchcraft Tini-QG) connector
5-pin Mini-XLR (Switchcraft Tini-QG) connector
Type
Connector
Connector
Family
Audio
Audio
Shape
round
round
Nominal contacts
4S351Source-backed nominal position/contact count for identification: 4. Not a pinout or manufacturing drawing.
5S352Source-backed nominal position/contact count for identification: 5. Not a pinout or manufacturing drawing.
Positions / cavity span
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Contact rows
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Connector role
plug (TA4MS11)S351Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. TA4MS11. Documented role: plug. Cable opening0.19/0.12/0.13in is wire acceptance,not connector geometry. Three/four/five pin counts do not assign any circuit function.
plug (TA5MBX)S352Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. TA5MBX. Documented role: plug. Cable opening0.19/0.12/0.13in is wire acceptance,not connector geometry. Three/four/five pin counts do not assign any circuit function.
Key distinction
Mini-XLR family name and conductor count identify a connector form; they do not establish the connected device signal, power scheme or contact assignment.
Mini-XLR family name and conductor count identify a connector form; they do not establish the connected device signal, power scheme or contact assignment.
Illustrations are computer-generated with prior AI visual review; independent technical and rights review pending. A comparison is not a compatibility verdict.
This comparison stays within one evidence layer.
All selected records are Connector records. Similar layer does not mean compatible, interchangeable or safe to mate.
Families represented: Audio
The reference ledger
Read the same question across.
2 selected records · 13 fields No score. No compatibility verdict.
Identification schematic · not to scale · drawing review pending
Layer
Connector
Connector
Key distinction
Mini-XLR family name and conductor count identify a connector form; they do not establish the connected device signal, power scheme or contact assignment.
Mini-XLR family name and conductor count identify a connector form; they do not establish the connected device signal, power scheme or contact assignment.
Nominal contacts
4S351Source-backed nominal position/contact count for identification: 4. Not a pinout or manufacturing drawing.
5S352Source-backed nominal position/contact count for identification: 5. Not a pinout or manufacturing drawing.
Positions / cavity span
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Populated contacts
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Contact rows
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Contact pitch
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Dimensions / axis
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Connector role
plug (TA4MS11)S351Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. TA4MS11. Documented role: plug. Cable opening0.19/0.12/0.13in is wire acceptance,not connector geometry. Three/four/five pin counts do not assign any circuit function.
plug (TA5MBX)S352Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. TA5MBX. Documented role: plug. Cable opening0.19/0.12/0.13in is wire acceptance,not connector geometry. Three/four/five pin counts do not assign any circuit function.
Coupling / latch
Button latch (TA4MS11)S351Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. TA4MS11. Documented role: plug. Cable opening0.19/0.12/0.13in is wire acceptance,not connector geometry. Three/four/five pin counts do not assign any circuit function.
Button latch (TA5MBX)S352Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. TA5MBX. Documented role: plug. Cable opening0.19/0.12/0.13in is wire acceptance,not connector geometry. Three/four/five pin counts do not assign any circuit function.
Keying / polarization
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Documented identification
Switchcraft’s cited Tini-QG product is identified as a Standard Connector Type Mini-XLR with 4 conductors.C310A
Switchcraft’s cited Tini-QG product is identified as a Standard Connector Type Mini-XLR with 5 conductors.C311A
Mini-XLR family name and conductor count identify a connector form; they do not establish the connected device signal, power scheme or contact assignment.
Mini-XLR family name and conductor count identify a connector form; they do not establish the connected device signal, power scheme or contact assignment.
plug (TA4MS11)S351Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. TA4MS11. Documented role: plug. Cable opening0.19/0.12/0.13in is wire acceptance,not connector geometry. Three/four/five pin counts do not assign any circuit function.
plug (TA5MBX)S352Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. TA5MBX. Documented role: plug. Cable opening0.19/0.12/0.13in is wire acceptance,not connector geometry. Three/four/five pin counts do not assign any circuit function.
Button latch (TA4MS11)S351Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. TA4MS11. Documented role: plug. Cable opening0.19/0.12/0.13in is wire acceptance,not connector geometry. Three/four/five pin counts do not assign any circuit function.
Button latch (TA5MBX)S352Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. TA5MBX. Documented role: plug. Cable opening0.19/0.12/0.13in is wire acceptance,not connector geometry. Three/four/five pin counts do not assign any circuit function.
Page scope: Evidence behind the compared records; the editorial comparison still needs separate review.
Assessment 2026-10-22 · earliest scheduled source review 2027-01-04. This is a recorded-date assessment, not a live source check. Page-level independent review is not established by this panel.
Scoped support: Product-specific identification of a 4-conductor Switchcraft Tini-QG Mini-XLR form only.
Not established / limitations: Source-backed identification does not establish universal wiring, protocol generation, device compatibility, safe installation or fabrication approval.
Locator: Configuration: number of conductors, product line and standard connector type
Scoped support: Product-specific identification of a 5-conductor Switchcraft Tini-QG Mini-XLR form only.
Not established / limitations: Source-backed identification does not establish universal wiring, protocol generation, device compatibility, safe installation or fabrication approval.
Locator: Configuration: number of conductors, product line and standard connector type
Scoped support: Manufacturer-example front mating-side numbering and latch context for 3-, 4- and 5-position sealed female Tini-QG connectors.
Not established / limitations: Numbered contact positions do not establish universal audio, power, microphone, intercom or device-specific signal wiring.
Locator: Front mating-side views for TA3FS, TA4FS and TA5FS with numbered contacts
Trace 3 claims to their source records
C310A · P310
Switchcraft’s cited Tini-QG product is identified as a Standard Connector Type Mini-XLR with 4 conductors.
Claim scope: V50 identification fact only; no wiring, protocol compatibility, installation or fabrication approval is inferred.
Switchcraft drawing TA_FS series revision B identifies F as female, S as sealed, and cable-size suffix 11 as the 2.54–3.05 mm range in its ordering code. The four-contact front view is labelled TA4FS series.
Claim scope: TA_FS customer drawing, one page, revision B dated 18-Dec-2015; no IP rating, exact suffix exterior difference or microphone pin assignment is inferred.
Recorded evidence only. An inspection date, publisher label, source link or generated packet is not independent technical review, hardware testing, fabrication approval or a compatibility verdict.
