The reference ledger
Read the same question across.
2 selected records · 13 fields No score. No compatibility verdict.
Identification schematic · not to scale · drawing review pending
Layer
Connector
Connector
Key distinction
MCX and MMCX are distinct miniature interfaces despite similar naming and snap-on behavior.
A smaller snap-on RF connector is not automatically MMCX; verify the exact family and mating geometry.
Nominal contacts
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Positions / cavity span
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Populated contacts
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Contact rows
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Contact pitch
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Dimensions / axis
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Connector role
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Coupling / latch
snap-on (Claim C228A); snap-on (Claim C228B); Push-onS232 · S252 · S232Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. V39 catalogue-expansion identification fact only; not independent technical approval, fabrication data, wiring instruction, protocol guarantee or end-to-end compatibility proof. V40 engineering-reference fact only; independent human review remains pending. This claim does not approve fabrication, rewiring, substitution, electrical safety, protocol support or end-to-end compatibility. Named series only, not every family part: Amphenol RF MCX product family. Family coupling is useful identification context but is not automatically counted as a polarization/keying fact.; No part suffix, row/contact pitch, dimensional axis, physical marking or universal performance limit inferred.; MCX page technical table2255VRMS conflicts with~225VRMS overview; voltage not adopted.
snap-on (Claim C229A); snap-on (Claim C229B); Push-onS233 · S253 · S233Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. V39 catalogue-expansion identification fact only; not independent technical approval, fabrication data, wiring instruction, protocol guarantee or end-to-end compatibility proof. V40 engineering-reference fact only; independent human review remains pending. This claim does not approve fabrication, rewiring, substitution, electrical safety, protocol support or end-to-end compatibility. Named series only, not every family part: Amphenol RF MMCX product family. Family coupling is useful identification context but is not automatically counted as a polarization/keying fact.; No part suffix, row/contact pitch, dimensional axis, physical marking or universal performance limit inferred.
Keying / polarization
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
Not recordedNot recorded in a normalized source-scoped field. Consult the exact part/revision; no value inferred from illustrations.
snap-on (Claim C228A); snap-on (Claim C228B); Push-onS232 · S252 · S232Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. V39 catalogue-expansion identification fact only; not independent technical approval, fabrication data, wiring instruction, protocol guarantee or end-to-end compatibility proof. V40 engineering-reference fact only; independent human review remains pending. This claim does not approve fabrication, rewiring, substitution, electrical safety, protocol support or end-to-end compatibility. Named series only, not every family part: Amphenol RF MCX product family. Family coupling is useful identification context but is not automatically counted as a polarization/keying fact.; No part suffix, row/contact pitch, dimensional axis, physical marking or universal performance limit inferred.; MCX page technical table2255VRMS conflicts with~225VRMS overview; voltage not adopted.
snap-on (Claim C229A); snap-on (Claim C229B); Push-onS233 · S253 · S233Named source examples retain separate role, part, view and axis limits; values are not a universal family specification. V39 catalogue-expansion identification fact only; not independent technical approval, fabrication data, wiring instruction, protocol guarantee or end-to-end compatibility proof. V40 engineering-reference fact only; independent human review remains pending. This claim does not approve fabrication, rewiring, substitution, electrical safety, protocol support or end-to-end compatibility. Named series only, not every family part: Amphenol RF MMCX product family. Family coupling is useful identification context but is not automatically counted as a polarization/keying fact.; No part suffix, row/contact pitch, dimensional axis, physical marking or universal performance limit inferred.
Two separately documented board jacks illustrate what to establish before choosing a component. Neither drawing makes these two parts mates or interchangeable replacements.
MMCX / Amphenol RF 908-22115
Component role
End-launch PCB jack
Recognition cue
Mating-side body to board-edge termination; inspect the named outline, not a generic catalog photo.
Declared product impedance
50 ohm for this named example only; not every connector sharing the family label.
Not established
Equipment identity, opposite part, application wiring, board layout suitability, performance of a complete path or interchangeability.
Next check
Verify both exact part numbers and current customer drawings. Keep mounting style, interface family and application requirements separate.
Observed 11 October 2026. Downloaded PDF page 1 (printed sheet 2 of 2), revision B. Left profile and centre axial view; title block part 908-22115.
Source discrepancy: Product page maximum temperature is 85 C; drawing notes +90 C. Neither temperature value is used in the illustration or chart. Revision reconciliation remains open.
Observed 11 October 2026. Downloaded PDF page 1 (printed sheet 2 of 2), revision A dated 4 July 2016. Left side profile and centre board-side axial view; title block part 919-384J-51P.
No nominal dimensions or temperature ratings have been imported into canonical evidence. These two visual-source observations are not new canonical claim/source records. The earlier family-level claims and dates remain unchanged.
Compare the named examples, not just the label.
The RF field guide keeps shell, centre contact, mounting role and the source discrepancy separate. No selected examples are approved as mates.
Page scope: Evidence behind the compared records; the editorial comparison still needs separate review.
Assessment 2026-10-22 · earliest scheduled source review 2027-01-03. This is a recorded-date assessment, not a live source check. Page-level independent review is not established by this panel.
Scoped support: Identifies MCX as a compact snap-on RF connector family available in multiple impedance/application variants.
Not established / limitations: Identification/reference scope only. V39 does not convert this source into a universal pinout, fabrication drawing, electrical approval, protocol guarantee or end-to-end compatibility verdict.
Scoped support: Identifies MMCX as a micro-miniature snap-on RF connector family distinct from MCX.
Not established / limitations: Identification/reference scope only. V39 does not convert this source into a universal pinout, fabrication drawing, electrical approval, protocol guarantee or end-to-end compatibility verdict.
Scoped support: Only Amphenol RF 919-NM174P51A1X, the named right-angle MCX plug. No family-wide geometry, mating pair, installed-cable performance or operating approval follows.
Not established / limitations: Text-only exact-part specification inspection. Customer drawing pixels not acquired; no dimensions, contact numbering, installation approval or hardware testing.
Locator: Full Product Specifications table: Body Material/Finish, Contact Material/Finish, Contact Termination, Termination Style, Coupling Mechanism, Orientation, Gender, Impedance (Ohms), Frequency (Max GHz), and Mating Cycles (Min).
Scoped support: Only Amphenol RF 262116TR, the named straight MMCX jack. No family-wide geometry, mating pair, installed-cable performance or operating approval follows.
Not established / limitations: Text-only exact-part specification inspection. Customer drawing pixels not acquired; no dimensions, contact numbering, installation approval or hardware testing.
Locator: Full Product Specifications table: Body Material/Finish, Contact Material/Finish, Contact Termination, Termination Style, Coupling Mechanism, Orientation, Gender, Impedance (Ohms), Frequency (Max GHz), and Mating Cycles (Min).
